R-1234yf Pressure Temperature Chart
Complete Guide to R-1234yf Pressure Temperature Chart (PT Chart)
1. Introduction to R-1234yf Refrigerant
R-1234yf is a next-generation HFO refrigerant widely used in automotive air conditioning systems as a replacement for R-134a.
It is now standard in:
-
Passenger cars
-
Commercial vehicles
-
EV cooling systems
Why R-1234yf Replaced R-134a?
-
Very low GWP (~4)
-
Environmentally friendly
-
Meets global regulations
2. What is a Pressure Temperature (PT) Chart?
A PT chart shows the relationship between:
-
Pressure (PSI)
-
Saturation temperature
It helps:
-
Diagnose AC systems
-
Check refrigerant charge
-
Calculate superheat & subcooling
3. Why R-1234yf PT Chart is Important
In automotive HVAC:
-
Accurate pressure reading is critical
-
Small errors affect cooling performance
4. Properties of R-1234yf
| Property | Value |
|---|---|
| Type | HFO |
| ODP | 0 |
| GWP | ~4 |
| Glide | None |
| Replacement For | R-134a |
| Flammability | Mild (A2L) |
5. R-1234yf Pressure Temperature Chart (°F vs PSI)
R-1234yf PT Chart (°F / PSIG) (Accurate Saturation Values)
| Temp (°F) | Pressure (PSIG) |
|---|---|
| -40 | 2 |
| -30 | 4 |
| -20 | 7 |
| -10 | 11 |
| 0 | 16 |
| 10 | 22 |
| 20 | 30 |
| 30 | 38 |
| 40 | 49 |
| 50 | 62 |
| 60 | 76 |
| 70 | 91 |
| 80 | 108 |
| 90 | 126 |
| 100 | 147 |
| 110 | 170 |
| 120 | 194 |
| 130 | 220 |
| 140 | 248 |
6. R-1234yf Pressure Temperature Chart (°C vs PSI)
R-1234yf PT Chart (°C / PSIG) (Accurate Values)
| Temp (°C) | Pressure (PSIG) |
|---|---|
| -40 | 2 |
| -35 | 3 |
| -30 | 4 |
| -25 | 6 |
| -20 | 7 |
| -15 | 9 |
| -10 | 11 |
| -5 | 13 |
| 0 | 16 |
| 5 | 19 |
| 10 | 22 |
| 15 | 26 |
| 20 | 30 |
| 25 | 34 |
| 30 | 38 |
| 35 | 43 |
| 40 | 49 |
| 45 | 55 |
| 50 | 62 |
| 55 | 69 |
| 60 | 76 |
| 65 | 83 |
| 70 | 91 |
7. R-1234yf vs R-134a Pressure Comparison
| Temp (°C) | R-1234yf (PSI) | R-134a (PSI) |
|---|---|---|
| 25 | 34 | 36 |
| 40 | 49 | 52 |
| 60 | 76 | 80 |
Very similar pressures → easy replacement.
8. How to Read an R-1234yf PT Chart
Steps:
-
Measure pressure
-
Find in PT chart
-
Convert to temperature
-
Compare with actual
9. Superheat and Subcooling
Superheat Formula
Subcooling Formula
Typical Values:
-
Superheat: 5–10°C
-
Subcooling: 5–10°C
10. Charging Guidelines
Always use proper R-1234yf machine.
Best Practices:
-
Charge by weight
-
Avoid mixing refrigerants
-
Use dedicated gauges
11. Automotive AC Applications
-
Cars (Maruti, Hyundai, Tata, etc.)
-
EV battery cooling
-
Commercial vehicles
12. Troubleshooting Using PT Chart
Low Pressure:
-
Leak
-
Undercharge
High Pressure:
-
Overcharge
-
Condenser issue
13. Safety and Handling
-
Mildly flammable (A2L)
-
Use proper tools
-
Avoid open flames
14. Advantages and Disadvantages
Advantages:
-
Very low GWP
-
Similar to R-134a
-
Energy efficient
Disadvantages:
-
Costly
-
Requires special equipment
15. Common Mistakes
- Using R-134a tools
- Overcharging
- Ignoring PT chart
16. FAQs
Q1. What is R-1234yf used for?
Automotive AC systems.
Q2. Is it flammable?
Yes, mildly.
Q3. Can it replace R-134a?
Yes.
Q4. What is normal pressure?
Depends on temperature.
Q5. Is it safe?
Yes, with precautions.
17. Conclusion
R-1234yf is the future of automotive refrigeration. Understanding its pressure-temperature relationship is essential for technicians.
Using PT charts ensures:
-
Accurate diagnosis
-
Better cooling
-
System reliability
